TSM180P03CS
-30V, -10A, SINGLE P-CHANNEL POWManufacturer: Taiwan Semiconductor Corporation
Categories: Single FETs, MOSFETs
Quality Control: Learn More
P-Channel 30 V 10A (Tc) 2.5W (Tc) Surface Mount 8-SOP
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 24 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-SOIC (0.154"", 3.90mm Width) |
| Mounting Type | Surface Mount |
| Operating Temperature | 150°C (TJ) |
| Technology | MOSFET (Metal Oxide) |
| FET Type | P-Channel |
| Current - Continuous Drain (Id) @ 25°C | 10A (Tc) |
| Rds On (Max) @ Id, Vgs | 18mOhm @ 8A, 10V |
| FET Feature | - |
| Power Dissipation (Max) | 2.5W (Tc) |
| Vgs(th) (Max) @ Id | 2.5V @ 250µA |
| Supplier Device Package | 8-SOP |
| Drive Voltage (Max Rds On, Min Rds On) | 4.5V, 10V |
| Vgs (Max) | ±20V |
| Drain to Source Voltage (Vdss) | 30 V |
| Gate Charge (Qg) (Max) @ Vgs | 14.6 nC @ 4.5 V |
| Input Capacitance (Ciss) (Max) @ Vds | 1730 pF @ 15 V |
Request a Quote
