TPMR10DH
35NS, 10A, 200V, SUPER FAST RECOManufacturer: Taiwan Semiconductor Corporation
Categories: Single Diodes
Quality Control: Learn More
Taiwan Semiconductor Corporation TPMR10DH is a Super Fast Recovery Rectifier diode designed for high-performance applications. This TO-277A (SMPC) surface mount component offers a reverse voltage rating of 200V and a forward current handling capability of 10A. It features a typical reverse recovery time of 35 ns and a forward voltage drop of 950 mV at 10A. The leakage current at 200V is a low 5 µA. With an operating junction temperature range of -55°C to 175°C and AEC-Q101 qualification, this diode is suited for automotive and power management applications. The capacitance at 4V and 1MHz is 140pF. It is supplied in Tape & Reel packaging.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: DiscontinuedPackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | TO-277, 3-PowerDFN |
| Mounting Type | Surface Mount |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Reverse Recovery Time (trr) | 35 ns |
| Technology | Standard |
| Capacitance @ Vr, F | 140pF @ 4V, 1MHz |
| Current - Average Rectified (Io) | 10A |
| Supplier Device Package | TO-277A (SMPC) |
| Operating Temperature - Junction | -55°C ~ 175°C |
| Grade | Automotive |
| Voltage - DC Reverse (Vr) (Max) | 200 V |
| Voltage - Forward (Vf) (Max) @ If | 950 mV @ 10 A |
| Current - Reverse Leakage @ Vr | 5 µA @ 200 V |
| Qualification | AEC-Q101 |
