SS310 R6
DIODE SCHOTTKY 100V 3A DO214ABManufacturer: Taiwan Semiconductor Corporation
Categories: Single Diodes
Quality Control: Learn More
Taiwan Semiconductor Corporation SS310-R6 is a 100V, 3A Schottky diode in a DO-214AB (SMC) surface mount package. This device features a maximum forward voltage drop of 850mV at 3A and a reverse leakage current of 100 µA at 100V. Operating across a junction temperature range of -55°C to 150°C, it is suitable for applications requiring efficient rectification and low forward voltage. The SS310-R6 is commonly utilized in power supply circuits, reverse polarity protection, and general-purpose rectification within the automotive, industrial, and consumer electronics sectors. It is supplied in Tape & Reel packaging.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: DiscontinuedPackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | DO-214AB, SMC |
| Mounting Type | Surface Mount |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Technology | Schottky |
| Capacitance @ Vr, F | - |
| Current - Average Rectified (Io) | 3A |
| Supplier Device Package | DO-214AB (SMC) |
| Operating Temperature - Junction | -55°C ~ 150°C |
| Voltage - DC Reverse (Vr) (Max) | 100 V |
| Voltage - Forward (Vf) (Max) @ If | 850 mV @ 3 A |
| Current - Reverse Leakage @ Vr | 100 µA @ 100 V |
