LL4003G L0G
DIODE GEN PURP 200V 1A MELFManufacturer: Taiwan Semiconductor Corporation
Categories: Single Diodes
Quality Control: Learn More
Taiwan Semiconductor Corporation's LL4003G-L0G is a general-purpose diode designed for high-reliability applications. This MELF packaged device offers a 200V reverse voltage (Vr) rating and a 1A average rectified forward current (Io). Key specifications include a maximum forward voltage (Vf) of 1.1V at 1A and a low reverse leakage current of 5 µA at 200V. The component exhibits a capacitance of 15pF @ 4V, 1MHz, and a standard recovery time exceeding 500ns. Operating across a wide temperature range from -65°C to 150°C, this diode is suitable for surface mount integration. The LL4003G-L0G is commonly found in power supplies, automotive electronics, and industrial control systems. It is supplied in Tape & Reel (TR) packaging.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | DO-213AB, MELF |
| Mounting Type | Surface Mount |
| Speed | Standard Recovery >500ns, > 200mA (Io) |
| Technology | Standard |
| Capacitance @ Vr, F | 15pF @ 4V, 1MHz |
| Current - Average Rectified (Io) | 1A |
| Supplier Device Package | MELF |
| Operating Temperature - Junction | -65°C ~ 150°C |
| Voltage - DC Reverse (Vr) (Max) | 200 V |
| Voltage - Forward (Vf) (Max) @ If | 1.1 V @ 1 A |
| Current - Reverse Leakage @ Vr | 5 µA @ 200 V |
