GP1607
DIODE ARRAY GP 16A TO220ABManufacturer: Taiwan Semiconductor Corporation
Categories: Diode Arrays
Quality Control: Learn More
Taiwan Semiconductor Corporation GP1607 is a diode array featuring a 1 pair common cathode configuration. This through-hole component, housed in a TO-220-3 package, offers a significant 16A average rectified current per diode. The forward voltage (Vf) is 1.1V at 8A, with a reverse leakage current of 10 µA at 1000V. Operating across a junction temperature range of -55°C to 150°C, the GP1607 utilizes standard recovery speed characteristics exceeding 500ns for currents above 200mA. This device is suitable for applications in power supplies, industrial controls, and automotive systems.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: DiscontinuedPackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | TO-220-3 |
| Mounting Type | Through Hole |
| Speed | Standard Recovery >500ns, > 200mA (Io) |
| Technology | Standard |
| Diode Configuration | 1 Pair Common Cathode |
| Current - Average Rectified (Io) (per Diode) | 16A |
| Supplier Device Package | TO-220AB |
| Operating Temperature - Junction | -55°C ~ 150°C |
| Voltage - Forward (Vf) (Max) @ If | 1.1 V @ 8 A |
| Current - Reverse Leakage @ Vr | 10 µA @ 1000 V |
