TS25P04G D2G

BRIDGE RECT 1P 400V 25A TS-6P

Manufacturer: Taiwan Semiconductor Corporation

Categories: Bridge Rectifiers

Quality Control: Learn More

Taiwan Semiconductor Corporation TS25P04G-D2G is a single-phase bridge rectifier featuring a 400V reverse voltage rating and a 25A average forward rectified current (Io). This through-hole component, housed in a TS-6P package, utilizes standard rectifier technology. It exhibits a maximum forward voltage (Vf) of 1.1V at 25A and a reverse leakage current of 10 µA at its peak reverse voltage. The TS25P04G-D2G operates across a temperature range of -55°C to 150°C (TJ). This component is suitable for applications in power supply units, industrial automation, and consumer electronics.

Additional Information

Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 22 week(s)Product Status: ActivePackaging: TubeDatasheet:
Technical Details:
PackagingTube
Package / Case4-SIP, TS-6P
Mounting TypeThrough Hole
Diode TypeSingle Phase
Operating Temperature-55°C ~ 150°C (TJ)
TechnologyStandard
Supplier Device PackageTS-6P
Voltage - Peak Reverse (Max)400 V
Current - Average Rectified (Io)25 A
Voltage - Forward (Vf) (Max) @ If1.1 V @ 25 A
Current - Reverse Leakage @ Vr10 µA @ 400 V
