SFSA480GU2AK2TO-C-8C-226-STD
SSD 480GB MSATA TLC SATAIII 3.3VManufacturer: Swissbit
Categories: Solid State Drives (SSDs), Hard Disk Drives (HDDs)
Quality Control: Learn More
Swissbit X-75M series 480GB mSATA Solid State Drive, part number SFSA480GU2AK2TO-C-8C-226-STD. This NAND TLC flash-based SSD utilizes the SATA III interface operating at 3.3V. It offers sequential read speeds up to 565MB/s and sequential write speeds up to 490MB/s. The compact mSATA form factor, measuring 50.80mm x 29.85mm x 3.30mm, is suitable for space-constrained applications. This component is designed for operation within an ambient temperature range of 0°C to 70°C and is supplied in bulk packaging. Applications include industrial automation, embedded systems, and communication infrastructure.
Additional Information
Series: X-75MRoHS Status: ROHS3 CompliantManufacturer Lead Time: 6 week(s)Product Status: Not For New DesignsPackaging: BulkDownload Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Size / Dimension | 50.80mm x 29.85mm x 3.30mm |
| Memory Size | 480GB |
| Memory Type | Solid State Drive (SSD) FLASH - NAND (TLC) |
| Type | SATA III |
| Weight | - |
| Operating Temperature | 0°C ~ 70°C |
| Voltage - Supply | 3.3V |
| Current - Max | - |
| Form Factor | mSATA |
| Speed - Read | 565MB/s |
| Speed - Write | 490MB/s |
