SFSA32GBV1BR4TO-C-NC-226-3V3
SSD 32GB SLIM-SATA SLC SATAIIIManufacturer: Swissbit
Categories: Solid State Drives (SSDs), Hard Disk Drives (HDDs)
Quality Control: Learn More
Swissbit X-200S series 32GB SLC SATA III Solid State Drive, part number SFSA32GBV1BR4TO-C-NC-226-3V3. This industrial-grade SSD utilizes SLC NAND flash for enhanced endurance and reliability, offering 32GB of storage capacity. It conforms to the Slim-SATA form factor and interfaces via SATA III, supporting a 3.3V supply voltage with a maximum current draw of 420mA. Sequential read speeds reach up to 100MB/s and write speeds up to 90MB/s. The unit measures 54.00mm x 39.00mm x 4.00mm and operates within a temperature range of 0°C to 70°C. This component is suitable for applications in industrial automation, embedded systems, and networking equipment. Packaged in trays.
Additional Information
Series: X-200SRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDownload Free CAD Model:
Technical Details:
| Packaging | Tray |
| Size / Dimension | 54.00mm x 39.00mm x 4.00mm |
| Memory Size | 32GB |
| Memory Type | Solid State Drive (SSD) FLASH - NAND (SLC) |
| Type | SATA III |
| Weight | 3.17 oz (90 g) |
| Operating Temperature | 0°C ~ 70°C |
| Voltage - Supply | 3.3V |
| Current - Max | 420mA |
| Form Factor | Slim-SATA |
| Speed - Read | 100MB/s |
| Speed - Write | 90MB/s |
