SFSA008GU4AA2TO-I-GS-22P-STD
SSD 8GB MSATA PSLC SATA III 3.3VManufacturer: Swissbit
Categories: Solid State Drives (SSDs), Hard Disk Drives (HDDs)
Quality Control: Learn More
Swissbit X-66M series SFSA008GU4AA2TO-I-GS-22P-STD is an 8GB mSATA Solid State Drive utilizing pSLC NAND flash technology. This component offers SATA III interface compliance with a 3.3V supply voltage. Designed for robust operation, it features a wide operating temperature range of -40°C to 85°C, making it suitable for demanding industrial applications. The drive delivers sequential read speeds of up to 520MB/s and write speeds of up to 450MB/s. Its compact mSATA form factor, measuring 50.80mm x 29.85mm x 3.30mm, along with a maximum current draw of 610mA, makes it ideal for embedded systems, industrial automation, and networking equipment.
Additional Information
Series: X-66MRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Size / Dimension | 50.80mm x 29.85mm x 3.30mm |
| Memory Size | 8GB |
| Memory Type | Solid State Drive (SSD) FLASH - NAND (pSLC) |
| Type | SATA III |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 3.3V |
| Current - Max | 610mA |
| Form Factor | mSATA |
| Speed - Read | 520MB/s |
| Speed - Write | 450MB/s |
