SFPC960GM1AG4TO-I-8C-516-STD
SSD 960GB M.2 PCIE NVME INDManufacturer: Swissbit
Categories: Solid State Drives (SSDs), Hard Disk Drives (HDDs)
Quality Control: Learn More
Swissbit N-10M2 series NVMe Solid State Drive (SSD) with part number SFPC960GM1AG4TO-I-8C-516-STD offers 960GB of NAND FLASH storage. This M.2 module, conforming to PCIe specifications, delivers sequential read speeds of up to 1.6GB/s and sequential write speeds of up to 1.1GB/s. Designed for industrial applications, it operates reliably across an extended temperature range of -40°C to 85°C. The M.2 2280 form factor (80.00mm x 22.00mm x 3.60mm) ensures broad compatibility in embedded systems, industrial automation, and networking infrastructure. This component is supplied in tray packaging.
Additional Information
Series: N-10M2RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDownload Free CAD Model:
Technical Details:
| Packaging | Tray |
| Size / Dimension | 80.00mm x 22.00mm x 3.60mm |
| Memory Size | 960GB |
| Memory Type | Solid State Drive (SSD) FLASH - NAND |
| Type | NVMe |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | - |
| Current - Max | - |
| Form Factor | M.2 Module, PCIe |
| Speed - Read | 1.6GB/s |
| Speed - Write | 1.1GB/s |
