XZDG25X92S-4
LED GREEN CLEAR CHIP SMDManufacturer: SunLED
Categories: LED Indication - Discrete
Quality Control: Learn More
SunLED XZDG25X92S-4 is a green LED indication component designed for surface mount applications. This discrete LED features a 525nm dominant wavelength, with a peak wavelength of 515nm, emitting a bright 6000mcd at a 150mA test current. The component is housed in a 4-SMD, J-Lead package with overall dimensions of 3.50mm L x 3.15mm W and a maximum height of 1.15mm. It offers a wide 120° viewing angle and a clear, colorless lens with a round, flat-top design measuring 2.60mm in diameter. The forward voltage is 3.5V, and it is supplied on a Tape & Reel (TR) for efficient automated assembly. This LED is commonly utilized in automotive, industrial automation, and consumer electronics for status indication and general lighting applications.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tape & Reel (TR) |
| Package / Case | 4-SMD, J-Lead |
| Color | Green |
| Size / Dimension | 3.50mm L x 3.15mm W |
| Mounting Type | Surface Mount |
| Millicandela Rating | 6000mcd |
| Configuration | Standard |
| Voltage - Forward (Vf) (Typ) | 3.5V |
| Lens Color | Colorless |
| Current - Test | 150mA |
| Viewing Angle | 120° |
| Height (Max) | 1.15mm |
| Wavelength - Peak | 515nm |
| Wavelength - Dominant | 525nm |
| Supplier Device Package | Chip LED |
| Lens Transparency | Clear |
| Lens Style | Round with Flat Top |
| Lens Size | 2.60mm Dia |
