XCMR32D
LED RED T-1 3MMManufacturer: SunLED
Categories: LED Indication - Discrete
Quality Control: Learn More
SunLED's XCMR32D is a red T-1 (3mm) radial LED with a forward voltage of 1.65V and a dominant wavelength of 640nm. This diffused, red-lensed component offers a peak wavelength of 660nm and a millicandela rating of 18mcd at a test current of 2mA. Featuring a round, domed top lens with a 2.90mm diameter and a 60° viewing angle, the XCMR32D is designed for through-hole mounting. Its dimensions are 3.20mm in diameter and a maximum height of 4.90mm. This discrete LED is utilized for indication purposes across various industries, including automotive, consumer electronics, and industrial automation. It is supplied in bulk packaging.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Package / Case | Radial |
| Color | Red |
| Size / Dimension | 3.20mm Dia |
| Mounting Type | Through Hole |
| Millicandela Rating | 18mcd |
| Configuration | Standard |
| Voltage - Forward (Vf) (Typ) | 1.65V |
| Lens Color | Red |
| Current - Test | 2mA |
| Viewing Angle | 60° |
| Height (Max) | 4.90mm |
| Wavelength - Peak | 660nm |
| Wavelength - Dominant | 640nm |
| Supplier Device Package | T-1 (3mm) |
| Lens Transparency | Diffused |
| Grade | - |
| Lens Style | Round with Domed Top |
| Lens Size | 2.90mm Dia |
| Qualification | - |
