MC1403DT
IC VREF SERIES 1% 8SOManufacturer: STMicroelectronics
Categories: Voltage Reference
Quality Control: Learn More
STMicroelectronics MC1403DT is a Series Voltage Reference IC providing a fixed 2.5V output with a ±1% tolerance. This component is designed for applications requiring precise voltage regulation, operating with an input voltage range of 4.5V to 40V and delivering a stable 2.5V. The MC1403DT offers a 10 mA output current capability with a typical supply current of 1.5 mA. It features a temperature coefficient of 40ppm/°C, ensuring reliable performance across its operating temperature range of 0°C to 70°C. The device is housed in an 8-SOIC package, suitable for surface mount applications. This voltage reference is commonly utilized in industrial, automotive, and consumer electronics systems demanding high accuracy and stability.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Tolerance | ±1% |
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-SOIC (0.154"", 3.90mm Width) |
| Temperature Coefficient | 40ppm/°C |
| Output Type | Fixed |
| Mounting Type | Surface Mount |
| Voltage - Input | 4.5V ~ 40V |
| Reference Type | Series |
| Operating Temperature | 0°C ~ 70°C (TA) |
| Current - Supply | 1.5mA |
| Supplier Device Package | 8-SOIC |
| Voltage - Output (Min/Fixed) | 2.5V |
| Noise - 0.1Hz to 10Hz | - |
| Noise - 10Hz to 10kHz | - |
| Current - Output | 10 mA |
