TSH345ID
IC AMP BUFFER 14SOManufacturer: STMicroelectronics
Categories: Video Amps and Modules
Quality Control: Learn More
STMicroelectronics TSH345ID is a triple high-speed buffer amplifier designed for video applications. This device offers a -3dB bandwidth of 36 MHz, making it suitable for signal amplification and buffering in a variety of electronic systems. Each channel provides a current output of 134 mA, and the device operates from a single or dual supply voltage range of 4.5V to 5.5V. The TSH345ID features three independent buffer amplifiers in a single package. It is supplied in a 14-SOIC package suitable for surface mount assembly. This component finds application in consumer electronics and broadcast equipment.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDownload Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 14-SOIC (0.154"", 3.90mm Width) |
| Output Type | - |
| Mounting Type | Surface Mount |
| Applications | Buffer |
| Slew Rate | - |
| Voltage - Supply, Single/Dual (±) | 4.5V ~ 5.5V |
| Supplier Device Package | 14-SO |
| Number of Circuits | 3 |
| Current - Supply | 44.6 mA |
| Current - Output / Channel | 134 mA |
| -3db Bandwidth | 36 MHz |
