USB6B1RL

TVS DIODE 5.25VWM 8-SO

Manufacturer: STMicroelectronics

Categories: TVS Diodes

Quality Control: Learn More

STMicroelectronics USB series steering TVS diode, part number USB6B1RL, offers robust transient voltage suppression for high-speed data lines. This 8-SOIC surface mount device is designed to protect sensitive components from electrostatic discharge (ESD) and other voltage transients. Featuring a 5.25V reverse standoff voltage and a 6V breakdown voltage, it effectively clamps surges to protect downstream circuitry. The USB6B1RL is rated for 500W peak pulse power and supports power line protection with its steering (rail-to-rail) configuration. Operating across a -40°C to 85°C temperature range, this component is suitable for applications in telecommunications, consumer electronics, and automotive systems where reliable protection of USB interfaces is critical. Packaged in Tape & Reel (TR), it facilitates automated assembly processes.

Additional Information

Series: USBRoHS Status: ROHS3 CompliantManufacturer Lead Time: 25 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:
Technical Details:
PackagingTape & Reel (TR)
Package / Case8-SOIC (0.154"", 3.90mm Width)
Mounting TypeSurface Mount
TypeSteering (Rail to Rail)
Operating Temperature-40°C ~ 85°C (TA)
ApplicationsGeneral Purpose
Capacitance @ Frequency-
Current - Peak Pulse (10/1000µs)-
Voltage - Reverse Standoff (Typ)5.25V
Supplier Device Package8-SOIC
Unidirectional Channels2
Voltage - Breakdown (Min)6V
Voltage - Clamping (Max) @ Ipp-
Power - Peak Pulse500W
Power Line ProtectionYes
