STRVS222X02F
TVS DIODE 154VWM 222VC DO201Manufacturer: STMicroelectronics
Categories: TVS Diodes
Quality Control: Learn More
The STMicroelectronics STRVS222X02F is a unidirectional TVS diode from the STRVS series, designed for robust transient voltage suppression. This axial leaded component, packaged in a DO-201AA (DO-27) case, features a reverse standoff voltage of 154V. It offers a minimum breakdown voltage of 171V and a maximum clamping voltage of 222V at a peak pulse current (IPP) of 2A, measured with an 8/20µs waveform. Operating reliably across an extended temperature range of -55°C to 175°C, this device is suitable for MOSFET protection applications. The STRVS222X02F is supplied in Tape & Box (TB) packaging.
Additional Information
Series: STRVSRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Box (TB)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Box (TB) |
| Package / Case | DO-201AA, DO-27, Axial |
| Mounting Type | Through Hole |
| Type | Zener |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Applications | MOSFET Protection |
| Capacitance @ Frequency | - |
| Current - Peak Pulse (10/1000µs) | 2A (8/20µs) |
| Voltage - Reverse Standoff (Typ) | 154V |
| Supplier Device Package | DO-201 |
| Unidirectional Channels | 1 |
| Voltage - Breakdown (Min) | 171V |
| Voltage - Clamping (Max) @ Ipp | 222V |
| Power - Peak Pulse | - |
| Power Line Protection | No |
