SMB6F5.0AY
TVS DIODE 5VWM 9.2VC SMBFLATManufacturer: STMicroelectronics
Categories: TVS Diodes
Quality Control: Learn More
STMicroelectronics SMB6F5-0AY is a 5V reverse standoff unidirectional TVS diode designed for robust transient voltage suppression. This AEC-Q101 qualified component offers a 6.4V minimum breakdown voltage and a 9.2V maximum clamping voltage at 68A peak pulse current (10/1000µs). With a 600W peak pulse power dissipation, it is engineered for demanding applications requiring protection against voltage surges. The SMBflat package (DO-221AA) facilitates efficient surface mounting and thermal management, operating reliably across a wide temperature range of -55°C to 175°C. Its suitability extends to automotive and industrial sectors where component integrity under transient stress is critical.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | DO-221AA, SMB Flat Leads |
| Mounting Type | Surface Mount |
| Type | Zener |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Applications | - |
| Capacitance @ Frequency | - |
| Current - Peak Pulse (10/1000µs) | 68A |
| Voltage - Reverse Standoff (Typ) | 5V |
| Supplier Device Package | SMBflat |
| Unidirectional Channels | 1 |
| Voltage - Breakdown (Min) | 6.4V |
| Voltage - Clamping (Max) @ Ipp | 9.2V |
| Power - Peak Pulse | 600W |
| Power Line Protection | No |
| Grade | Automotive |
| Qualification | AEC-Q101 |
