LNBTVS6-221S
TVS DIODE 20VWM 32VC SMCManufacturer: STMicroelectronics
Categories: TVS Diodes
Quality Control: Learn More
STMicroelectronics LNBTVS6-221S is a unidirectional TRANSIL™ diode from the LNBTVS series, designed for robust transient voltage suppression. This surface mount device, packaged in a DO-214AB (SMC) case, offers a reverse standoff voltage of 20V and a breakdown voltage of 22V minimum. It features a maximum clamping voltage of 32V at a peak pulse current of 500A (8/20µs), with a peak pulse power dissipation of 22.5kW. The operating temperature range is -55°C to 150°C. This component is widely utilized in general-purpose applications, providing protection against voltage transients in automotive, industrial, and consumer electronics. The device is supplied in tape and reel packaging.
Additional Information
Series: LNBTVS, TRANSIL™RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | DO-214AB, SMC |
| Mounting Type | Surface Mount |
| Type | Zener |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Applications | General Purpose |
| Capacitance @ Frequency | - |
| Current - Peak Pulse (10/1000µs) | 500A (8/20µs) |
| Voltage - Reverse Standoff (Typ) | 20V |
| Supplier Device Package | SMC |
| Unidirectional Channels | 1 |
| Voltage - Breakdown (Min) | 22V |
| Voltage - Clamping (Max) @ Ipp | 32V |
| Power - Peak Pulse | 22500W (22.5kW) |
| Power Line Protection | No |
