DDSL01-030SL
TVS DIODE 30VWM SOT23-3Manufacturer: STMicroelectronics
Categories: TVS Diodes
Quality Control: Learn More
STMicroelectronics DSL Series TVS Diode, part number DDSL01-030SL, offers robust transient voltage suppression in a compact SOT-23-3 package. This surface mount device is designed for general-purpose applications requiring voltage protection up to 30V reverse standoff. Operating across a temperature range of -40°C to 125°C (TJ), the DDSL01-030SL is suitable for demanding environments. Its steering (rail to rail) architecture and single unidirectional channel provide effective protection against voltage surges. The component is supplied in Tape & Reel (TR) packaging, facilitating automated assembly processes in industries such as automotive, industrial control, and consumer electronics.
Additional Information
Series: DSLRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | TO-236-3, SC-59, SOT-23-3 |
| Mounting Type | Surface Mount |
| Type | Steering (Rail to Rail) |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Applications | General Purpose |
| Capacitance @ Frequency | - |
| Current - Peak Pulse (10/1000µs) | - |
| Voltage - Reverse Standoff (Typ) | 30V |
| Supplier Device Package | SOT-23-3 |
| Unidirectional Channels | 1 |
| Voltage - Breakdown (Min) | - |
| Voltage - Clamping (Max) @ Ipp | - |
| Power - Peak Pulse | - |
| Power Line Protection | No |
