T610T-8FP
TRIAC SENS GATE 800V TO-220FPABManufacturer: STMicroelectronics
Categories: TRIACs
Quality Control: Learn More
STMicroelectronics T610T-8FP is a single, logic-sensitive gate TRIAC designed for high-voltage AC power control applications. This component features an 800V off-state voltage and a 6A RMS on-state current capability. The sensitive gate design requires a maximum trigger current (Igt) of 10mA and a maximum trigger voltage (Vgt) of 1.3V, facilitating control with low-power logic devices. It exhibits a holding current (Ih) of 15mA and non-repetitive surge current handling of 45A at 50Hz and 47A at 60Hz.
The T610T-8FP is housed in a TO-220FPAB package, a through-hole mounting type offering effective thermal management. Its operating temperature range spans from -40°C to 150°C (TJ). This TRIAC is suitable for use in motor control, lighting control, and general AC power switching across industrial and consumer electronics sectors.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | TO-220-3 Full Pack |
| Mounting Type | Through Hole |
| Triac Type | Logic - Sensitive Gate |
| Configuration | Single |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Current - Hold (Ih) (Max) | 15 mA |
| Current - Gate Trigger (Igt) (Max) | 10 mA |
| Current - Non Rep. Surge 50, 60Hz (Itsm) | 45A, 47A |
| Voltage - Gate Trigger (Vgt) (Max) | 1.3 V |
| Supplier Device Package | TO-220FPAB |
| Current - On State (It (RMS)) (Max) | 6 A |
| Voltage - Off State | 800 V |
Request a Quote
Clients Also Buy
T1250H-6T
TRIAC ALTERNISTOR 600V 12A TO220
Z0410MF 1AA2
