T1620T-6I
TRIAC ALTERNISTOR 600V 16A TO220Manufacturer: STMicroelectronics
Categories: TRIACs
Quality Control: Learn More
STMicroelectronics T1620T-6I is a Snubberless™ TRIAC ALTERNISTOR designed for robust AC power control applications. This single-configuration component features a 600V off-state voltage and a maximum on-state current of 16A RMS. It is housed in a standard TO-220-3 through-hole package, facilitating straightforward PCB integration. The T1620T-6I exhibits a typical gate trigger current (Igt) of 20mA and a hold current (Ih) of 25mA, with a maximum gate trigger voltage (Vgt) of 1.3V. It can withstand non-repetitive surge currents of 120A at 50Hz and 126A at 60Hz. Operating across a temperature range of -40°C to 125°C (TJ), this TRIAC is well-suited for use in applications such as motor control, lighting systems, and power switching in industrial and consumer electronics.
Additional Information
Series: Snubberless™RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | TO-220-3 |
| Mounting Type | Through Hole |
| Triac Type | Alternistor - Snubberless |
| Configuration | Single |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Current - Hold (Ih) (Max) | 25 mA |
| Current - Gate Trigger (Igt) (Max) | 20 mA |
| Current - Non Rep. Surge 50, 60Hz (Itsm) | 120A, 126A |
| Voltage - Gate Trigger (Vgt) (Max) | 1.3 V |
| Supplier Device Package | TO-220 |
| Current - On State (It (RMS)) (Max) | 16 A |
| Voltage - Off State | 600 V |
