T1210T-8FP
TRIAC SENS GATE 800V 12A TO220ABManufacturer: STMicroelectronics
Categories: TRIACs
Quality Control: Learn More
STMicroelectronics T1210T-8FP is a single, logic-sensitive gate TRIAC designed for high-voltage AC power control applications. This component features an 800V off-state voltage and a 12A RMS on-state current capability. The sensitive gate requires a maximum trigger current (Igt) of 10mA and a trigger voltage (Vgt) of 1.3V, facilitating control with lower power trigger circuits. Its robust design includes a non-repetitive surge current rating of 90A at 50Hz and 95A at 60Hz. The device is housed in a TO-220FPAB package, a full pack configuration suitable for through-hole mounting. Operating within a junction temperature range of -40°C to 150°C, the T1210T-8FP is utilized in industrial motor control, lighting control, and power switching systems.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | TO-220-3 Full Pack |
| Mounting Type | Through Hole |
| Triac Type | Logic - Sensitive Gate |
| Configuration | Single |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Current - Hold (Ih) (Max) | 15 mA |
| Current - Gate Trigger (Igt) (Max) | 10 mA |
| Current - Non Rep. Surge 50, 60Hz (Itsm) | 90A, 95A |
| Voltage - Gate Trigger (Vgt) (Max) | 1.3 V |
| Supplier Device Package | TO-220FPAB |
| Current - On State (It (RMS)) (Max) | 12 A |
| Voltage - Off State | 800 V |
