STGWA20H65DFB2
IGBT TRENCH FS 650V 40A TO247Manufacturer: STMicroelectronics
Categories: Single IGBTs
Quality Control: Learn More
IGBT Trench Field Stop 650 V 40 A 147 W Through Hole TO-247 Long Leads
Additional Information
Series: HB2RoHS Status: ROHS3 CompliantManufacturer Lead Time: 15 week(s)Product Status: ActivePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | TO-247-3 |
| Mounting Type | Through Hole |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Input Type | Standard |
| Reverse Recovery Time (trr) | 215 ns |
| Vce(on) (Max) @ Vge, Ic | 2.1V @ 15V, 20A |
| Supplier Device Package | TO-247 Long Leads |
| IGBT Type | Trench Field Stop |
| Td (on/off) @ 25°C | 16ns/78.8ns |
| Switching Energy | 265µJ (on), 214µJ (off) |
| Test Condition | 400V, 20A, 10Ohm, 15V |
| Gate Charge | 56 nC |
| Grade | - |
| Current - Collector (Ic) (Max) | 40 A |
| Voltage - Collector Emitter Breakdown (Max) | 650 V |
| Current - Collector Pulsed (Icm) | 60 A |
| Power - Max | 147 W |
| Qualification | - |
