STGP10NC60HD
IGBT 600V 20A 65W TO220Manufacturer: STMicroelectronics
Categories: Single IGBTs
Quality Control: Learn More
STMicroelectronics STGP10NC60HD is a 600 V, 20 A PowerMESH™ series IGBT with a maximum power dissipation of 65 W. This device features a low Vce(on) of 2.5V at 15V, 5A and a fast switching capability characterized by Td(on/off) of 14.2ns/72ns at 25°C, with switching energy of 31.8µJ (on) and 95µJ (off) under test conditions of 390V, 5A, 10Ohm, 15V. The STGP10NC60HD is housed in a TO-220-3 package suitable for through-hole mounting and operates across a wide temperature range of -55°C to 150°C (TJ). This component is utilized in applications such as power supplies, industrial motor drives, and renewable energy systems.
Additional Information
Series: PowerMESH™RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | TO-220-3 |
| Mounting Type | Through Hole |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Input Type | Standard |
| Reverse Recovery Time (trr) | 22 ns |
| Vce(on) (Max) @ Vge, Ic | 2.5V @ 15V, 5A |
| Supplier Device Package | TO-220 |
| IGBT Type | - |
| Td (on/off) @ 25°C | 14.2ns/72ns |
| Switching Energy | 31.8µJ (on), 95µJ (off) |
| Test Condition | 390V, 5A, 10Ohm, 15V |
| Gate Charge | 19.2 nC |
| Current - Collector (Ic) (Max) | 20 A |
| Voltage - Collector Emitter Breakdown (Max) | 600 V |
| Current - Collector Pulsed (Icm) | 30 A |
| Power - Max | 65 W |
