STP20NK50Z
MOSFET N-CH 500V 17A TO220ABManufacturer: STMicroelectronics
Categories: Single FETs, MOSFETs
Quality Control: Learn More
N-Channel 500 V 17A (Tc) 190W (Tc) Through Hole TO-220
Additional Information
Series: SuperMESH™RoHS Status: ROHS3 CompliantManufacturer Lead Time: 13 week(s)Product Status: ActivePackaging: TubeDownload Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | TO-220-3 |
| Mounting Type | Through Hole |
| Operating Temperature | -50°C ~ 150°C (TJ) |
| Technology | MOSFET (Metal Oxide) |
| FET Type | N-Channel |
| Current - Continuous Drain (Id) @ 25°C | 17A (Tc) |
| Rds On (Max) @ Id, Vgs | 270mOhm @ 8.5A, 10V |
| FET Feature | - |
| Power Dissipation (Max) | 190W (Tc) |
| Vgs(th) (Max) @ Id | 4.5V @ 100µA |
| Supplier Device Package | TO-220 |
| Drive Voltage (Max Rds On, Min Rds On) | 10V |
| Vgs (Max) | ±30V |
| Drain to Source Voltage (Vdss) | 500 V |
| Gate Charge (Qg) (Max) @ Vgs | 119 nC @ 10 V |
| Input Capacitance (Ciss) (Max) @ Vds | 2600 pF @ 25 V |
