STL9P3LLH6
MOSFET P-CH 30V 9A POWERFLATManufacturer: STMicroelectronics
Categories: Single FETs, MOSFETs
Quality Control: Learn More
The STMicroelectronics STL9P3LLH6 is a P-Channel MOSFET from the STripFET™ H6 series, designed for efficient power switching applications. This component features a Drain-Source Voltage (Vdss) of 30V and a continuous Drain Current (Id) of 9A at 25°C (Tc). With a maximum Rds On of 15mOhm at 4.5A and 10V, it offers low conduction losses. The device is available in an 8-PowerVDFN package, specifically the 3.3x3.3 PowerFlat™ footprint, suitable for surface mounting. Key electrical parameters include a Gate Charge (Qg) of 24nC at 4.5V and an Input Capacitance (Ciss) of 2615pF at 25V. The operating temperature range is -55°C to 150°C. This MOSFET is commonly utilized in automotive, industrial, and consumer electronics sectors for power management and conversion tasks.
Additional Information
Series: STripFET™ H6RoHS Status: ROHS3 CompliantManufacturer Lead Time: 26 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-PowerVDFN |
| Mounting Type | Surface Mount |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Technology | MOSFET (Metal Oxide) |
| FET Type | P-Channel |
| Current - Continuous Drain (Id) @ 25°C | 9A (Tc) |
| Rds On (Max) @ Id, Vgs | 15mOhm @ 4.5A, 10V |
| FET Feature | - |
| Power Dissipation (Max) | 3W (Ta) |
| Vgs(th) (Max) @ Id | 1V @ 250µA (Min) |
| Supplier Device Package | PowerFlat™ (3.3x3.3) |
| Drive Voltage (Max Rds On, Min Rds On) | 4.5V, 10V |
| Vgs (Max) | ±20V |
| Drain to Source Voltage (Vdss) | 30 V |
| Gate Charge (Qg) (Max) @ Vgs | 24 nC @ 4.5 V |
| Input Capacitance (Ciss) (Max) @ Vds | 2615 pF @ 25 V |
