STTH8R06G-TR
DIODE GEN PURP 600V 8A D2PAKManufacturer: STMicroelectronics
Categories: Single Diodes
Quality Control: Learn More
STMicroelectronics STTH8R06G-TR is a high-performance, fast recovery diode designed for demanding applications. This surface mount component, housed in a TO-263-3, D2PAK package, offers a voltage rating of 600 V and an average rectified current capability of 8 A. The STTH8R06G-TR features a low reverse leakage of 30 µA at 600 V and a forward voltage drop of 2.9 V at 8 A. With a reverse recovery time of 45 ns, this diode is suitable for use in power supply rectification, motor control, and lighting systems. The component operates at junction temperatures up to 175°C (Max) and is supplied in Tape & Reel packaging.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 25 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB |
| Mounting Type | Surface Mount |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Reverse Recovery Time (trr) | 45 ns |
| Technology | Standard |
| Capacitance @ Vr, F | - |
| Current - Average Rectified (Io) | 8A |
| Supplier Device Package | D2PAK |
| Operating Temperature - Junction | 175°C (Max) |
| Voltage - DC Reverse (Vr) (Max) | 600 V |
| Voltage - Forward (Vf) (Max) @ If | 2.9 V @ 8 A |
| Current - Reverse Leakage @ Vr | 30 µA @ 600 V |
