STTH30S06W
DIODE GEN PURP 600V 30A DO247-2Manufacturer: STMicroelectronics
Categories: Single Diodes
Quality Control: Learn More
STMicroelectronics STTH30S06W is a general-purpose, fast-recovery diode designed for high-voltage applications. This component features a maximum reverse voltage (Vr) of 600 V and a forward voltage (Vf) of 3.6 V at a continuous forward current (Io) of 30 A. The reverse leakage current is rated at 50 µA at 600 V. With a reverse recovery time (trr) of 50 ns, it is classified as a fast recovery diode. The device operates within a junction temperature range of -40°C to 175°C and is housed in a DO-247-2 package with straight leads, suitable for through-hole mounting. This diode is commonly employed in power supply rectification, motor control, and industrial power applications demanding robust performance and efficient switching.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | DO-247-2 (Straight Leads) |
| Mounting Type | Through Hole |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Reverse Recovery Time (trr) | 50 ns |
| Technology | Standard |
| Capacitance @ Vr, F | - |
| Current - Average Rectified (Io) | 30A |
| Operating Temperature - Junction | -40°C ~ 175°C |
| Voltage - DC Reverse (Vr) (Max) | 600 V |
| Voltage - Forward (Vf) (Max) @ If | 3.6 V @ 30 A |
| Current - Reverse Leakage @ Vr | 50 µA @ 600 V |
