STPS20SM60ST
DIODE SCHOTTKY 60V 20A TO220Manufacturer: STMicroelectronics
Categories: Single Diodes
Quality Control: Learn More
STMicroelectronics STPS20SM60ST is a 60V, 20A Schottky diode designed for high-efficiency power rectification. Featuring a low forward voltage drop of 630mV at 20A, this device minimizes power loss in demanding applications. The STPS20SM60ST is housed in a TO-220 package with a through-hole mounting type, facilitating straightforward integration into existing circuit designs. Its reverse leakage current is rated at 85 µA at 60 V, ensuring robust performance. With a maximum operating junction temperature of 150°C, this diode is well-suited for use in automotive power supplies, industrial power management, and renewable energy systems. The device's fast recovery characteristics contribute to improved overall system efficiency.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDownload Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | TO-220-3 |
| Mounting Type | Through Hole |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Technology | Schottky |
| Capacitance @ Vr, F | - |
| Current - Average Rectified (Io) | 20A |
| Supplier Device Package | TO-220 |
| Operating Temperature - Junction | 150°C (Max) |
| Voltage - DC Reverse (Vr) (Max) | 60 V |
| Voltage - Forward (Vf) (Max) @ If | 630 mV @ 20 A |
| Current - Reverse Leakage @ Vr | 85 µA @ 60 V |
