X00602MA 2AL2
SCR 600V 800MA TO92-3Manufacturer: STMicroelectronics
Categories: SCRs
Quality Control: Learn More
SCR 600 V 800 mA Sensitive Gate Through Hole TO-92-3
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Cut Tape (CT)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Cut Tape (CT) |
| Package / Case | TO-226-3, TO-92-3 (TO-226AA) Formed Leads |
| Mounting Type | Through Hole |
| SCR Type | Sensitive Gate |
| Operating Temperature | -40°C ~ 125°C |
| Current - Hold (Ih) (Max) | 5 mA |
| Current - Gate Trigger (Igt) (Max) | 200 µA |
| Current - Non Rep. Surge 50, 60Hz (Itsm) | 9A, 10A |
| Current - On State (It (AV)) (Max) | 500 mA |
| Voltage - Gate Trigger (Vgt) (Max) | 800 mV |
| Voltage - On State (Vtm) (Max) | 1.35 V |
| Current - Off State (Max) | 1 µA |
| Supplier Device Package | TO-92-3 |
| Current - On State (It (RMS)) (Max) | 800 mA |
| Voltage - Off State | 600 V |
