TDA7540N
RF RECEIVER AM/FM 10.7MHZ 80LQFPManufacturer: STMicroelectronics
Categories: RF Receivers
Quality Control: Learn More
STMicroelectronics TDA7560N is a highly integrated RF receiver designed for AM and FM broadcast reception at a 10.7MHz intermediate frequency. This component features a surface mountable 80-LQFP (14x14) package, facilitating efficient PCB layout. Operating within a supply voltage range of 7.7V to 9V, the TDA7560N exhibits a typical receiving current of 12mA. It is engineered for automotive applications, supporting both AM and FM modulation. The device is supplied in trays.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDownload Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tray |
| Package / Case | 80-LQFP |
| Sensitivity | - |
| Mounting Type | Surface Mount |
| Frequency | 10.7MHz |
| Memory Size | - |
| Modulation or Protocol | AM, FM |
| Data Interface | PCB, Surface Mount |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 7.7V ~ 9V |
| Applications | Audio |
| Current - Receiving | 12mA |
| Data Rate (Max) | - |
| Antenna Connector | PCB, Surface Mount |
| Supplier Device Package | 80-LQFP (14x14) |
| Grade | Automotive |
