VNQ6004SATR-E
IC PWR DRVR N-CHAN 1:1 PWRSSO36Manufacturer: STMicroelectronics
Categories: Power Distribution Switches, Load Drivers
Quality Control: Learn More
The STMicroelectronics VIPower™ VNQ6004SATR-E is a high-side power driver IC featuring four N-channel switches. This device offers robust protection including current limiting (fixed), open load detection, over-temperature, and over-voltage protection, with an auto-restart feature. It supports an output current capability of up to 25A and a peak of 55A, with typical on-resistance values of 10mOhm and 30mOhm. The VNQ6004SATR-E operates across a load voltage range of 5V to 28V and is designed for a junction temperature range of -40°C to 150°C. Communication with the device is facilitated via an SPI interface. It is supplied in a 36-PowerFSOP (PowerSSO-36) package, suitable for surface mounting, and is delivered in tape and reel packaging. This component finds application in automotive systems, industrial automation, and general power distribution.
Additional Information
Series: VIPower™RoHS Status: ROHS3 CompliantManufacturer Lead Time: 26 week(s)Product Status: Not For New DesignsPackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | Auto Restart |
| Packaging | Tape & Reel (TR) |
| Package / Case | 36-PowerFSOP (0.295"", 7.50mm Width) |
| Output Type | N-Channel |
| Mounting Type | Surface Mount |
| Number of Outputs | 4 |
| Interface | SPI |
| Switch Type | General Purpose |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Output Configuration | High Side |
| Rds On (Typ) | 10mOhm, 30mOhm |
| Input Type | - |
| Voltage - Load | 5V ~ 28V |
| Voltage - Supply (Vcc/Vdd) | - |
| Current - Output (Max) | 25A, 55A |
| Ratio - Input:Output | 1:1 |
| Supplier Device Package | PowerSSO-36 |
| Fault Protection | Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage |
