VNL5050S5-E
IC PWR DRIVER N-CHANNEL 1:1 8SOManufacturer: STMicroelectronics
Categories: Power Distribution Switches, Load Drivers
Quality Control: Learn More
STMicroelectronics VNL5050S5-E is a single-channel N-channel power switch from the OMNIFET III™, VIPower™ series. This device, packaged in an 8-SOIC, offers a robust solution for power distribution and load driving applications. It features a maximum output current of 19A and a low on-resistance of 50mOhm typical. Integrated fault protection mechanisms include fixed current limiting, over-temperature shutdown, and over-voltage protection, complemented by auto-restart functionality and a status flag for system monitoring. The VNL5050S5-E operates with a supply voltage range of 3.5V to 5.5V and supports a maximum load voltage of 36V. Its surface mount design is suitable for high-volume manufacturing in automotive and industrial automation sectors.
Additional Information
Series: OMNIFET III™, VIPower™RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Features | Auto Restart, Status Flag |
| Packaging | Tube |
| Package / Case | 8-SOIC (0.154"", 3.90mm Width) |
| Output Type | N-Channel |
| Mounting Type | Surface Mount |
| Number of Outputs | 1 |
| Interface | ON/OFF |
| Switch Type | General Purpose |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Output Configuration | Low Side |
| Rds On (Typ) | 50mOhm (Max) |
| Input Type | Non-Inverting |
| Voltage - Load | 36V (Max) |
| Voltage - Supply (Vcc/Vdd) | 3.5V ~ 5.5V |
| Current - Output (Max) | 19A |
| Ratio - Input:Output | 1:1 |
| Supplier Device Package | 8-SOIC |
| Fault Protection | Current Limiting (Fixed), Over Temperature, Over Voltage |
