VND9008AJTR
LINEAR IC'SManufacturer: STMicroelectronics
Categories: Power Distribution Switches, Load Drivers
Quality Control: Learn More
The STMicroelectronics VND9008AJTR is a high-side power switch driver featuring a 1:1 ratio with dual N-Channel outputs. This automotive-grade component, qualified to AEC-Q100, delivers a maximum output current of 67A. It offers comprehensive fault protection including fixed current limiting, overload, over-temperature, over-voltage, reverse battery, and undervoltage lockout (UVLO). Key features include auto-restart functionality and a status flag for system monitoring. The device operates with a supply voltage range of 4V to 28V and has a typical Rds On of 9.4mOhm. Packaged in a PowerSSO-16 (16-PowerLFSOP) for surface mounting, the VND9008AJTR is suitable for demanding applications in the automotive sector, such as power distribution and load driving. The operating temperature range is -40°C to 150°C (TJ).
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 26 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | Auto Restart, Status Flag |
| Packaging | Tape & Reel (TR) |
| Package / Case | 16-PowerLFSOP (0.154"", 3.90mm Width) |
| Output Type | N-Channel |
| Mounting Type | Surface Mount |
| Number of Outputs | 2 |
| Interface | Logic |
| Switch Type | General Purpose |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Output Configuration | High Side |
| Rds On (Typ) | 9.4mOhm |
| Input Type | Non-Inverting |
| Voltage - Load | - |
| Voltage - Supply (Vcc/Vdd) | 4V ~ 28V |
| Current - Output (Max) | 67A |
| Ratio - Input:Output | 1:1 |
| Supplier Device Package | PowerSSO-16 |
| Fault Protection | Current Limiting (Fixed), Over Load, Over Temperature, Over Voltage, Reverse Battery, UVLO |
| Grade | Automotive |
| Qualification | AEC-Q100 |
