VN920
IC PWR DRVR N-CH 1:1 5PENTAWATTManufacturer: STMicroelectronics
Categories: Power Distribution Switches, Load Drivers
Quality Control: Learn More
The STMicroelectronics VN920 is a single-channel, high-side N-channel power switch from the VIPower™ series. This device offers a 1:1 input to output ratio and is designed for general-purpose applications. It features robust fault protection including fixed current limiting, over-temperature protection, and over-voltage protection, coupled with auto-restart functionality. The VN920 supports a load voltage range of 5.5V to 36V and can deliver up to 30A of output current. Its low on-resistance, typically 16mOhm, minimizes power dissipation. The device is housed in a Pentawatt-5 (Vertical, Bent and Staggered Leads) package, suitable for through-hole mounting. This component is commonly utilized in automotive and industrial control systems.
Additional Information
Series: VIPower™RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDownload Free CAD Model:
Technical Details:
| Features | Auto Restart |
| Packaging | Tube |
| Package / Case | Pentawatt-5 (Vertical, Bent and Staggered Leads) |
| Output Type | N-Channel |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Interface | ON/OFF |
| Switch Type | General Purpose |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Output Configuration | High Side |
| Rds On (Typ) | 16mOhm (Max) |
| Input Type | Non-Inverting |
| Voltage - Load | 5.5V ~ 36V |
| Voltage - Supply (Vcc/Vdd) | Not Required |
| Current - Output (Max) | 30A |
| Ratio - Input:Output | 1:1 |
| Supplier Device Package | 5-PENTAWATT |
| Fault Protection | Current Limiting (Fixed), Over Temperature, Over Voltage |
