VN820-B5
IC PWR DRIVER N-CHAN 1:1 P2PAKManufacturer: STMicroelectronics
Categories: Power Distribution Switches, Load Drivers
Quality Control: Learn More
STMicroelectronics VN820-B5 is a versatile 1:1 N-Channel power driver designed for high-side switching applications. This component offers robust fault protection, including fixed current limiting, open load detection, over-temperature protection, and over-voltage protection. Key features include auto-restart functionality and a status flag for monitoring. With a maximum continuous output current of 9A and a low on-resistance of 40mOhm typical, it is suitable for demanding power distribution tasks. The VN820-B5 operates within a load voltage range of 5.5V to 36V and an extended junction temperature range of -40°C to 150°C. Its P2PAK (4 leads + tab) package facilitates surface mounting. This device finds application in automotive systems, industrial automation, and power management solutions.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDownload Free CAD Model:
Technical Details:
| Features | Auto Restart, Status Flag |
| Packaging | Tube |
| Package / Case | P2PAK (4 Leads + Tab) |
| Output Type | N-Channel |
| Mounting Type | Surface Mount |
| Number of Outputs | 1 |
| Interface | ON/OFF |
| Switch Type | General Purpose |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Output Configuration | High Side |
| Rds On (Typ) | 40mOhm (Max) |
| Input Type | Non-Inverting |
| Voltage - Load | 5.5V ~ 36V |
| Voltage - Supply (Vcc/Vdd) | Not Required |
| Current - Output (Max) | 9A |
| Ratio - Input:Output | 1:1 |
| Supplier Device Package | P2PAK |
| Fault Protection | Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage |
