VN750
IC PWR DRVR N-CH 1:1 5PENTAWATTManufacturer: STMicroelectronics
Categories: Power Distribution Switches, Load Drivers
Quality Control: Learn More
STMicroelectronics VN750 is a single-channel, high-side power switch from the VIPower™ series. This N-channel MOSFET driver is designed for general-purpose applications, offering a maximum continuous output current of 6A. The device features robust fault protection including fixed current limiting, over-temperature shutdown, over-voltage protection, and open-load detection, with an auto-restart function and status flag for diagnostics. It operates over a wide temperature range of -40°C to 150°C (TJ) and utilizes a non-inverting input with a simple ON/OFF interface. The output configuration is high-side, and the device comes in a 5-PENTAWATT package with through-hole mounting. The on-resistance (Rds On) is a typical 60mOhm. This component is suitable for automotive and industrial applications requiring reliable power switching and protection.
Additional Information
Series: VIPower™RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Features | Auto Restart, Status Flag |
| Packaging | Tube |
| Package / Case | Pentawatt-5 (Vertical, Bent and Staggered Leads) |
| Output Type | N-Channel |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Interface | ON/OFF |
| Switch Type | General Purpose |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Output Configuration | High Side |
| Rds On (Typ) | 60mOhm (Max) |
| Input Type | Non-Inverting |
| Voltage - Load | 5.5V ~ 36V |
| Voltage - Supply (Vcc/Vdd) | Not Required |
| Current - Output (Max) | 6A |
| Ratio - Input:Output | 1:1 |
| Supplier Device Package | 5-PENTAWATT |
| Fault Protection | Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage |
