VN31
IC PWR DRVR N-CH 1:1 5PENTAWATTManufacturer: STMicroelectronics
Categories: Power Distribution Switches, Load Drivers
Quality Control: Learn More
STMicroelectronics VN31 is a high-side N-channel power switch/driver designed for robust power control applications. This general-purpose device features a 1:1 input-to-output ratio and delivers a maximum output current of 31A. Built with integrated fault protection, it includes open-load detection and over-temperature shutdown capabilities, with a status flag to indicate operational status. The VN31 offers a low on-resistance of typically 30mOhm and operates across a load voltage range of 5.5V to 26V. Its output configuration is high-side, and the input type is non-inverting, controlled via a simple ON/OFF interface. Housed in a 5-PENTAWATT package with vertical, bent, and staggered leads, this component is suitable for through-hole mounting. The VN31 finds application in automotive and industrial control systems requiring reliable power distribution.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Features | Status Flag |
| Packaging | Tube |
| Package / Case | Pentawatt-5 (Vertical, Bent and Staggered Leads) |
| Output Type | N-Channel |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Interface | ON/OFF |
| Switch Type | General Purpose |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Output Configuration | High Side |
| Rds On (Typ) | 30mOhm (Max) |
| Input Type | Non-Inverting |
| Voltage - Load | 5.5V ~ 26V |
| Voltage - Supply (Vcc/Vdd) | Not Required |
| Current - Output (Max) | 31A |
| Ratio - Input:Output | 1:1 |
| Supplier Device Package | 5-PENTAWATT |
| Fault Protection | Open Load Detect, Over Temperature |
