VNH2SP30-E
IC MTR DRV 5.5-16V MULTIPWRSO-30Manufacturer: STMicroelectronics
Categories: Motor Drivers, Controllers
Quality Control: Learn More
STMicroelectronics VNH2SP30-E, a high-side motor driver from the VIPower™ series, is engineered for demanding automotive applications. This fully integrated component combines control and power stages, delivering robust performance for brushed DC motor control. Featuring a Power MOSFET technology and a Half Bridge (2) output configuration, it supports a voltage range of 5.5V to 16V for both supply and load. With a substantial 30A output current capability, the VNH2SP30-E is optimized for efficient Pulse Width Modulation (PWM) interfacing. Its MultiPowerSO-30 package facilitates surface mounting and ensures operation across an extended temperature range of -40°C to 150°C. This device is ideal for automotive systems requiring precise and powerful motor actuation.
Additional Information
Series: STripFET™, VIPower™RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: DiscontinuedPackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 30-MPSO, MultiPowerSO |
| Mounting Type | Surface Mount |
| Function | Driver - Fully Integrated, Control and Power Stage |
| Current - Output | 30A |
| Interface | PWM |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Output Configuration | Half Bridge (2) |
| Voltage - Supply | 5.5V ~ 16V |
| Applications | - |
| Technology | Power MOSFET |
| Voltage - Load | 5.5V ~ 16V |
| Supplier Device Package | MultiPowerSO-30 |
| Motor Type - Stepper | - |
| Motor Type - AC, DC | Brushed DC |
| Step Resolution | - |
| Grade | Automotive |
