L6219DSA13TR
IC MTR DRV BIPLR 4.75-5.25V 24SOManufacturer: STMicroelectronics
Categories: Motor Drivers, Controllers
Quality Control: Learn More
STMicroelectronics L6219DSA13TR is a bipolar stepper motor driver IC featuring a parallel interface. This fully integrated component combines control and power stages, offering a robust solution for brushed DC and bipolar stepper motor applications. It provides four half-bridge output configurations and supports step resolutions of 1 and 1/2 steps. The device operates with a supply voltage range of 4.75V to 5.25V and a load voltage range of 10V to 46V. With an output current capability of 750mA, it is suitable for general-purpose applications across various industries. The L6219DSA13TR is packaged in a 24-SOIC (0.295", 7.50mm Width) surface-mount package and is supplied on tape and reel. Its operating temperature range is -40°C to 150°C (TJ).
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 24-SOIC (0.295"", 7.50mm Width) |
| Mounting Type | Surface Mount |
| Function | Driver - Fully Integrated, Control and Power Stage |
| Current - Output | 750mA |
| Interface | Parallel |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Output Configuration | Half Bridge (4) |
| Voltage - Supply | 4.75V ~ 5.25V |
| Applications | General Purpose |
| Technology | - |
| Voltage - Load | 10V ~ 46V |
| Supplier Device Package | 24-SO |
| Motor Type - Stepper | Bipolar |
| Motor Type - AC, DC | Brushed DC |
| Step Resolution | 1, 1/2 |
