L6205D
IC MTR DRVR BIPOLAR 8-52V 20SOICManufacturer: STMicroelectronics
Categories: Motor Drivers, Controllers
Quality Control: Learn More
The STMicroelectronics STSPIN L62 L6205D is a bipolar stepper motor driver featuring a fully integrated control and power stage. This BiCDMOS device operates from an 8V to 52V supply voltage and delivers up to 2.8A per channel. Its parallel interface facilitates direct control of bipolar stepper motors. The L6205D integrates four half-bridge output configurations within a 20-SOIC package, suitable for surface mount applications. This component is designed for general-purpose use across industries requiring precise motor control, including industrial automation and robotics. The operating temperature range is -25°C to 125°C (TJ).
Additional Information
Series: STSPIN L62RoHS Status: ROHS3 CompliantManufacturer Lead Time: 30 week(s)Product Status: ActivePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 20-SOIC (0.295"", 7.50mm Width) |
| Mounting Type | Surface Mount |
| Function | Driver - Fully Integrated, Control and Power Stage |
| Current - Output | 2.8A |
| Interface | Parallel |
| Operating Temperature | -25°C ~ 125°C (TJ) |
| Output Configuration | Half Bridge (4) |
| Voltage - Supply | 8V ~ 52V |
| Applications | General Purpose |
| Technology | BiCDMOS |
| Voltage - Load | 8V ~ 52V |
| Supplier Device Package | 20-SO |
| Motor Type - Stepper | Bipolar |
| Motor Type - AC, DC | Brushed DC |
| Step Resolution | - |
