STR730FZ2T7
IC MCU 32BIT 256KB FLASH 144LQFPManufacturer: STMicroelectronics
Categories: Microcontrollers
Quality Control: Learn More
STMicroelectronics STR7 microcontroller, part number STR730FZ2T7, features an ARM7® 32-bit single-core processor operating at 36MHz. This IC offers 256KB of FLASH program memory and 16KB of RAM. Connectivity options include CANbus, I2C, SPI, and UART/USART interfaces. It is equipped with a 16x10-bit Analog-to-Digital converter and peripherals such as DMA, POR, PWM, and WDT. With 112 I/O lines and a 144-LQFP surface mount package, this device operates within a temperature range of -40°C to 105°C (TA) and a supply voltage of 4.5V to 5.5V. The STR7 series component is suitable for applications in industrial automation and consumer electronics.
Additional Information
Series: STR7RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDownload Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 144-LQFP |
| Mounting Type | Surface Mount |
| Speed | 36MHz |
| Program Memory Size | 256KB (256K x 8) |
| RAM Size | 16K x 8 |
| Operating Temperature | -40°C ~ 105°C (TA) |
| Oscillator Type | Internal |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| Core Processor | ARM7® |
| Data Converters | A/D 16x10b |
| Core Size | 32-Bit Single-Core |
| Voltage - Supply (Vcc/Vdd) | 4.5V ~ 5.5V |
| Connectivity | CANbus, I2C, SPI, UART/USART |
| Peripherals | DMA, POR, PWM, WDT |
| Number of I/O | 112 |
| Programmable | Not Verified |
