ST7FLITE39F2M3TR
IC MCU 8BIT 8KB FLASH 20SOManufacturer: STMicroelectronics
Categories: Microcontrollers
Quality Control: Learn More
STMicroelectronics ST7 series microcontroller, the ST7FLITE39F2M3TR, is an 8-bit device featuring an ST7 core operating at up to 16MHz. This component offers 8KB of FLASH program memory and 384 bytes of RAM, with an additional 256 bytes of EEPROM for data storage. Connectivity options include LINbus and SCI, alongside SPI. The device incorporates a 7-channel, 10-bit Analog-to-Digital converter. On-chip peripherals include Low Voltage Detect (LVD), Power-On Reset (POR), Pulse Width Modulation (PWM), and Watchdog Timer (WDT). Housed in a 20-SOIC package with surface mount capability, this microcontroller is designed for operation across an industrial temperature range of -40°C to 125°C. It supports a supply voltage from 2.7V to 5.5V. The ST7FLITE39F2M3TR is suitable for applications in automotive and industrial control systems.
Additional Information
Series: ST7RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 20-SOIC (0.295"", 7.50mm Width) |
| Mounting Type | Surface Mount |
| Speed | 16MHz |
| Program Memory Size | 8KB (8K x 8) |
| RAM Size | 384 x 8 |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Oscillator Type | Internal |
| Program Memory Type | FLASH |
| EEPROM Size | 256 x 8 |
| Core Processor | ST7 |
| Data Converters | A/D 7x10b |
| Core Size | 8-Bit |
| Voltage - Supply (Vcc/Vdd) | 2.7V ~ 5.5V |
| Connectivity | LINbusSCI, SPI |
| Peripherals | LVD, POR, PWM, WDT |
| Supplier Device Package | 20-SO |
| Number of I/O | 15 |
| Programmable | Not Verified |
Request a Quote
