ST72F561K6TCS
IC MCU 8BIT 32KB FLASH 32LQFPManufacturer: STMicroelectronics
Categories: Microcontrollers
Quality Control: Learn More
STMicroelectronics ST7 series microcontroller, part number ST72F561K6TCS, offers an 8-bit ST7 core operating at 8MHz. This component features 32KB of FLASH program memory and 2KB of RAM. Connectivity options include CANbus, LINbus, SCI, and SPI interfaces. The device is equipped with a 16-channel 10-bit Analog-to-Digital converter and includes peripherals such as LVD, POR, PWM, and WDT. Designed for surface mounting, it comes in a 32-LQFP (7x7) package and supports 48 I/O lines. The operating voltage range is 4.5V to 5.5V, with an operating temperature range of -40°C to 125°C. This component is AEC-Q100 qualified and suitable for automotive applications.
Additional Information
Series: ST7RoHS Status: ROHS3 CompliantManufacturer Lead Time: 52 week(s)Product Status: Not For New DesignsPackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 32-LQFP |
| Mounting Type | Surface Mount |
| Speed | 8MHz |
| Program Memory Size | 32KB (32K x 8) |
| RAM Size | 2K x 8 |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Oscillator Type | External |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| Core Processor | ST7 |
| Data Converters | A/D 16x10b |
| Core Size | 8-Bit |
| Voltage - Supply (Vcc/Vdd) | 4.5V ~ 5.5V |
| Connectivity | CANbus, LINbus, SCI, SPI |
| Peripherals | LVD, POR, PWM, WDT |
| Supplier Device Package | 32-LQFP (7x7) |
| Grade | Automotive |
| Number of I/O | 48 |
| Programmable | Not Verified |
| Qualification | AEC-Q100 |
