L78M08ACDT-TR
IC REG LINEAR 8V 500MA DPAKManufacturer: STMicroelectronics
Categories: Linear, Low Drop Out (LDO) Regulators
Quality Control: Learn More
STMicroelectronics L78M08ACDT-TR is a positive fixed 8V linear voltage regulator with a 500mA output current capability. This device is housed in a TO-252-3, DPAK (2 Leads + Tab), SC-63 surface mount package. It offers robust protection features including over current, over temperature, and short circuit protection. The regulator exhibits a typical quiescent current of 6 mA and a power supply rejection ratio (PSRR) of 56dB at 120Hz. With an input voltage range up to 35V, the L78M08ACDT-TR is suitable for applications in industrial automation, consumer electronics, and telecommunications. It operates within an ambient temperature range of 0°C to 125°C and is supplied on a tape and reel.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | TO-252-3, DPAK (2 Leads + Tab), SC-63 |
| Output Type | Fixed |
| Mounting Type | Surface Mount |
| Current - Output | 500mA |
| Operating Temperature | 0°C ~ 125°C |
| Output Configuration | Positive |
| Current - Quiescent (Iq) | 6 mA |
| Voltage - Input (Max) | 35V |
| Number of Regulators | 1 |
| Supplier Device Package | DPAK |
| Voltage - Output (Max) | - |
| Voltage - Output (Min/Fixed) | 8V |
| Control Features | - |
| PSRR | 56dB (120Hz) |
| Voltage Dropout (Max) | - |
| Protection Features | Over Current, Over Temperature, Short Circuit |
