STP16CPS05M
IC LED DRIVER LINEAR 100MA 24SOPManufacturer: STMicroelectronics
Categories: LED Drivers
Quality Control: Learn More
STMicroelectronics STP16CPS05M is a 16-channel linear LED driver featuring a shift register topology. This device is capable of delivering up to 100mA per channel with a maximum output voltage of 20V. The internal switches allow for direct LED control, simplifying system design. Operating from a 3V to 5.5V supply, the STP16CPS05M is engineered for efficient driving of LED arrays. Its 24-SOP package facilitates surface mounting for compact board layouts. This component is suitable for applications requiring precise control and high-density LED illumination, commonly found in visual display systems and general lighting solutions. The device operates within an ambient temperature range of -40°C to 125°C and supports a clock frequency of up to 30MHz.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 24-SOIC (0.295"", 7.50mm Width) |
| Voltage - Output | 20V |
| Mounting Type | Surface Mount |
| Number of Outputs | 16 |
| Frequency | 30MHz |
| Type | Linear |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Applications | - |
| Current - Output / Channel | 100mA |
| Internal Switch(s) | Yes |
| Topology | Shift Register |
| Supplier Device Package | 24-SOP |
| Dimming | - |
| Voltage - Supply (Min) | 3V |
| Voltage - Supply (Max) | 5.5V |
