TS942IPT
IC OPAMP GP 2 CIRCUIT 8TSSOPManufacturer: STMicroelectronics
Categories: Instrumentation, Op Amps, Buffer Amps
Quality Control: Learn More
The STMicroelectronics TS942IPT is a general-purpose operational amplifier featuring two independent channels. This device offers rail-to-rail output capability, enhancing dynamic range in demanding applications. With a low input bias current of 1 pA and a quiescent current of 1.2 µA per channel, it is well-suited for power-sensitive designs. The TS942IPT boasts a gain bandwidth product of 10 kHz and a slew rate of 0.0045 V/µs, suitable for signal conditioning and buffering in instrumentation and industrial automation. Packaged in an 8-TSSOP, it supports surface mounting and operates across a temperature range of -40°C to 85°C, with a supply voltage span from 2.5 V to 10 V.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-TSSOP (0.173"", 4.40mm Width) |
| Output Type | Rail-to-Rail |
| Mounting Type | Surface Mount |
| Amplifier Type | General Purpose |
| Operating Temperature | -40°C ~ 85°C |
| Current - Supply | 1.2µA (x2 Channels) |
| Slew Rate | 0.0045V/µs |
| Gain Bandwidth Product | 10 kHz |
| Current - Input Bias | 1 pA |
| Voltage - Input Offset | 10 mV |
| Supplier Device Package | 8-TSSOP |
| Number of Circuits | 2 |
| Current - Output / Channel | 5 mA |
| Voltage - Supply Span (Min) | 2.5 V |
| Voltage - Supply Span (Max) | 10 V |
