MASTERGAN3TR
IC HALF BRIDGE DRV 6.5A/4A 31QFNManufacturer: STMicroelectronics
Categories: Full Half-Bridge (H Bridge) Drivers
Quality Control: Learn More
Half Bridge Driver DC-DC Converters DMOS 31-QFN (9x9)
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 16 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | Bootstrap Circuit |
| Packaging | Tape & Reel (TR) |
| Package / Case | 31-VQFN Exposed Pad |
| Mounting Type | Surface Mount |
| Interface | Logic |
| Operating Temperature | -40°C ~ 125°C |
| Output Configuration | Half Bridge |
| Voltage - Supply | 3.3V ~ 15V |
| Rds On (Typ) | 225mOhm LS, 450mOhm HS |
| Applications | DC-DC Converters |
| Current - Output / Channel | 6.5A, 4A |
| Current - Peak Output | 6.5A, 4A |
| Technology | DMOS |
| Voltage - Load | 3.3V ~ 15V |
| Supplier Device Package | 31-QFN (9x9) |
| Fault Protection | Over Temperature, UVLO |
| Load Type | Inductive, Capacitive, Resistive |
