STTH30AC06CP
DIODE ARRAY GP 600V 15A TO3PFManufacturer: STMicroelectronics
Categories: Diode Arrays
Quality Control: Learn More
STMicroelectronics STTH30AC06CP is a fast recovery diode array housed in a TO-3PF package. This component features two diodes configured in a common cathode arrangement, each capable of handling an average rectified current of 15A. The reverse voltage rating is 600V, with a low leakage current of 10 µA at 600V. The forward voltage drop is specified at a maximum of 1.95V when conducting 15A. With a reverse recovery time (trr) of 55 ns, this diode array is suitable for high-frequency applications. It operates across a wide temperature range from -65°C to 175°C. This device finds application in power supplies, motor control, and industrial automation systems.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | TO-3PF |
| Mounting Type | Through Hole |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Reverse Recovery Time (trr) | 55 ns |
| Technology | Standard |
| Diode Configuration | 1 Pair Common Cathode |
| Current - Average Rectified (Io) (per Diode) | 15A |
| Supplier Device Package | TO-3PF |
| Operating Temperature - Junction | -65°C ~ 175°C |
| Voltage - DC Reverse (Vr) (Max) | 600 V |
| Voltage - Forward (Vf) (Max) @ If | 1.95 V @ 15 A |
| Current - Reverse Leakage @ Vr | 10 µA @ 600 V |
