STPS41H100CG
DIODE ARR SCHOTT 100V 20A D2PAKManufacturer: STMicroelectronics
Categories: Diode Arrays
Quality Control: Learn More
STMicroelectronics STPS41H100CG is a 100V, 20A Schottky diode array featuring a common cathode configuration. This device is housed in a TO-263-3, D2PAK package, suitable for surface mount applications. The STPS41H100CG offers a low forward voltage of 800mV at 20A and a reverse leakage of 10µA at 100V. Its high junction operating temperature of 175°C (Max) makes it robust for demanding environments. This component is commonly utilized in power supply rectification, reverse polarity protection, and switching power applications across industries such as telecommunications, industrial automation, and automotive systems.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 25 week(s)Product Status: ActivePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB |
| Mounting Type | Surface Mount |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Technology | Schottky |
| Diode Configuration | 1 Pair Common Cathode |
| Current - Average Rectified (Io) (per Diode) | 20A |
| Supplier Device Package | D2PAK |
| Operating Temperature - Junction | 175°C (Max) |
| Voltage - DC Reverse (Vr) (Max) | 100 V |
| Voltage - Forward (Vf) (Max) @ If | 800 mV @ 20 A |
| Current - Reverse Leakage @ Vr | 10 µA @ 100 V |
